Drive Motor Resistance:
120 Volt 2,460 – 3,100 Ohms
240 Volt 10,000 - 13,000 Ohms
24 Volt 80 - 130 Ohms
1. Terminal 1
2. Terminal 2
3. Terminal 3
4. Terminal 4
5. Terminal 5
6. Terminal 6
7. Motor Disconnect Block
8. Motor Switch
9. Motor and Exhaust Assembly
10. Drive Motor
Figure 12
Test Procedures
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
54 Part No. D515519R3
