ALLIANCE STENYFSP175TW01 User Manual

Is proper electrical
power supplied to
coin drop? (Incorrect
electrical connection
may prevent coins
from registering in
coin drop.)
Is machine level?
(Machines that aren't
level may prevent
coins from following
through required
check stages of drop.)
Yes
Refer to wiring
diagram for proper
connections.
No
Is coin drop clean?
(Residue or lint
build-up may prevent
coins from following
through required
check stages of drop.)
Refer to Installation
Instructions for
instructions on
leveling machine.
No
Do coins fall freely
through drop?
Yes
Refer to Adjustments
section for
instructions on
cleaning drop.
No
Replace coin drop
sensor.
Yes
Replace coin drop.
No
Electronic Coin Drops
If coin drop is not accepting coins, perform the following:
1. Clean coin drop. Refer to Cleaning Electronic Coin Drop.
2. On electronic coin drops with an old-style tension spring
(shown in Figure 3 and Figure 4 ), test and replace tension
spring using the following instructions.
Remove Coin Drop From Machine
1. Disconnect electrical power to machine and drop.
2. Remove coin drop from machine.
Test Tension Spring
1. Push coin return button to open and close coin drop cover to
clear possible coin jams. Refer to Figure 3 .
Coin Drop Troubleshooting
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
50 Part No. D515519R3
