PDA Does Not Communicate With Control
Attempt to communicate with the electronic control using the PDA.
Is there
acknowledgement from
the control?
Check PDA set-up: Com
port, Baud Rate,
Consumer IR Bit
Yes
Check PDA manual for
correct use of IR. Is
there any control
response?
No
Does the electronic
control display EI0F
or -C-?
No
If PDA displays
control mismatch,
select proper control
type.
Yes
Has IR communication
been turned off?
EI0F
Communication
sequence checks out
properly.
-C-
Change electronic
control and repeat
procedure.
No
Turn IR communication
on (refer to
programming manual).
Yes
Make sure that SDIO
IrDA card is
installed if
required on PDA.
No
Yes
Electronic Control Troubleshooting
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
38 Part No. D515519R3
