Coin Drop Troubleshooting
WARNING
To reduce the risk of electric shock, fire, explosion,
serious injury or death:
• Disconnect electric power to the dryer before
servicing.
• Close gas shut-of valve to gas dryer before serv-
icing.
• Never start the Dryer with any guards/panels re-
moved.
• Whenever ground wires are removed during serv-
icing, these ground wires must be reconnected to
ensure that the dryer is properly grounded.
W001R1
Non-Electronic Coin Drops
When coin is placed into coin slot, the coin should roll down
drop and be heard dropping into coin vault. If coin does not fall
into coin vault or if coin drop sensor does not register that coin
has been entered, follow troubleshooting instructions on follow-
ing page. Refer to Figure 2 for path that coin follows when work-
ing properly.
IMPORTANT: Never use oil to correct coin drop prob-
lems. Oil residue will prevent coins from rolling proper-
ly.
IMPORTANT: Do not bend or damage mechanical parts
within coin drop.
1. Coin Drop Sensor
2. Additional Coins Following Path to Sensor
3. Coin in Coin Slot
Figure 2
Coin Drop Troubleshooting
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
49 Part No. D515519R3
