Chapter 1: Overview
18
Front and Back Panels
Figure 1 illustrates the front panels of the AT-GS908M, AT-GS916M, and
AT-GS924M Gigabit Ethernet Switches.
Figure 1. AT-GS908M, AT-GS916M, and AT-GS924M Front Panels
AT-GS924M
AT-GS916M
10/100/1000Base-T
Twisted-Pair Ports
AT-GS908M
Reset Button
Port LEDs
SFP LED
Console Port
Status LEDs
Mode
Button
Mode
LEDs
SFP Slot
10/100/1000Base-T
Twisted-Pair Ports
Reset Button
Port LEDs
SFP LEDs
Console Port
Status LEDs
Mode
Button
Mode
LEDs
10/100/1000Base-T
Twisted-Pair Ports
Reset Button
Port LEDs
SFP LEDs
Console Port
Status LEDs
Mode
Button
Mode
LEDs
SFP Slots
SFP Slots
