51
Appendix A
Technical Specifications
This appendix contains the following specifications:
“Physical Specifications”
“Environmental Specifications” on page 52
“Power Specifications” on page 52
“Safety and Electromagnetic Emissions Certifications” on page 52
“Connectors and Port Pinouts” on page 53
Physical Specifications
Dimensions
Weight
Table 9. Chassis Dimensions
Model W x D x H mm (in)
AT-GS908M 263 mm x 179 mm x 38 mm
(10.35 in x 7.0 in x 1.5 in)
AT-GS916M 341 mm x 210 mm x 44 mm
(13.4 in x 8.3 in x 1.7 in)
AT-GS924M 440 mm x 210 mm x 44 mm
(17.32 in x 8.3 in x 1.7 in)
Table 10. Chassis Weight
Model kg (lbs)
AT-GS908M 1.4 kg (3.09 lbs)
AT-GS916M 2.0 kg (4.41 lbs)
AT-GS924M 2.7 kg (5.95 lbs)
