AT-S63 Management Software Features Guide
Section II: Advanced Operations 145
The next example limits the ingress traffic on port 17 to IP packets from
the subnet 149.22.11.0 and a Type of Service setting of 6, destined to the
end node with the IP address 149.22.22.22. All other IP traffic and ARP
packets are prohibited.
Figure 12. ACL Example 6
Create Access Control Lists (ACL)
1 - ACL ID ................. 4
2 - Description .......... ToS 6 traffic - permit
3 - Action .................. Permit
4 - Classifier List ...... 6
5 - Port List .............. 17
Create Classifier
01 - Classifier ID: ...... 6
02 - Description: ....... ToS 6 subnet flow
.
.
09 - IP ToS: ............... 6
.
12 - Src IP Addr: ....... 149.22.11.0
13 - Src IP Mask: ...... 255.255.255.0
14 - Dst IP Addr: ....... 149.22.22.22
15 - Dst IP Mask: ......
Create Access Control Lists (ACL)
1 - ACL ID ................. 23
2 - Description .......... All IP flow - deny
3 - Action .................. Deny
4 - Classifier List ...... 8,67
5 - Port List .............. 17
Create Classifier
01 - Classifier ID: ..... 8
02 - Description: ...... All IP flow
.
.
08 - Protocol: ........... IP
Create Classifier
01 - Classifier ID: ..... 67
02 - Description: ...... All ARP flow
.
.
08 - Protocol: ........... 0x806 (ARP)
