12 x530 Series Quick Installation Guide
To install the switch on a wall, perform the following procedure:
1. Place the switch on a table.
2. If the bumper feet are attached to the bottom of the switch,
remove them using a flat-head screwdriver.
3. For the x530-28GTXm and x530-28GPXm Switches, attach two
brackets with eight screws, as shown here.
Warning: The device should be installed on the wall by a
qualified building contractor. Serious injury to yourself or
others or damage to the equipment may result if it is not
properly fastened to the wall. E105
Caution: The supplied screws and anchors might not be
suitable for all walls. A qualified building contractor
should determine the hardware requirements of your wall
prior to installing the switch.
E88
