Allied 4DHV Mini-Split Series - Capacity Data; Cooling and Heating Capacity - 24 (208;230 V)

508067-01 Issue 2016 Page 19 of 75
COOLING CAPACITY - 24 (208/230V)
Outdoor
Temperature - °F
(Dry Bulb)
Indoor Temperature - °F (Dry Bulb / Wet Bulb)
65°F / 54°F 70°F / 59°F 75°F / 63°F 80°F / 67°F
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
–13 18.76 14.06 19.78 14.81 20.90 15.83 22.47 17.19
–5 20.06 15.12 21.38 16.13 22.59 16.80 24.16 18.14
–4 20.34 14.76 21.94 15.92 23.05 16.73 24.66 18.10
0 21.23 15.30 22.75 16.40 23.64 17.06 25.42 18.33
5 21.53 17.12 23.08 18.36 24.25 19.25 25.94 20.46
15 21.18 17.10 22.98 18.55 24.01 19.29 25.68 20.55
25 21.22 16.54 22.36 17.43 23.63 18.36 25.41 19.45
35 20.90 16.27 22.29 17.35 23.55 18.34 25.18 19.31
45 20.59 15.52 22.21 16.75 23.33 17.59 24.95 18.82
55 20.64 14.98 22.13 16.06 22.99 16.68 24.72 17.94
65 20.33 14.66 21.80 15.72 22.90 16.51 24.49 17.66
75 20.02 15.92 21.72 17.27 22.69 18.04 24.26 19.30
85 20.17 16.28 21.25 17.16 22.46 18.13 24.15 19.50
95 19.95 15.55 21.28 16.58 22.48 17.52 24.04 18.73
105 18.94 14.75 20.43 15.91 21.47 16.71 22.96 17.88
110 18.02 14.67 19.32 15.72 20.18 16.34 21.58 17.33
115 16.75 15.44 17.96 16.56 18.77 17.08 20.18 18.29
122 15.32 14.68 16.62 15.93 17.36 16.64 18.56 17.80
HEATING CAPACITY - 24 (208/230V)
Outdoor
Temperature - °F
(Dry Bulb)
Indoor Temperature - °F (Dry Bulb)
60°F 65°F 70°F 75°F
Total
mBtuh
Total
mBtuh
Total
mBtuh
Total
mBtuh
–13 12.34 11.86 11.47 11.07
–5 14.70 14.13 13.65 13.04
0 16.35 15.71 15.17 14.48
5 17.95 17.20 16.67 16.00
17 21.14 20.26 19.61 18.53
19.4 21.54 20.60 19.96 18.96
24.8 22.07 21.09 20.44 19.52
32 22.55 21.59 20.90 20.06
35 23.23 22.24 21.51 20.75
39.2 25.25 24.15 23.36 22.42
44.6 28.28 27.15 26.24 25.32
47 29.63 28.33 27.46 26.36
53.6 30.72 29.39 28.45 27.02
57 31.83 30.44 29.44 27.82
