Allied 4DHV Mini-Split Series - Capacity Data; Cooling and Heating Capacity - 36 (208;230 V)

508067-01Issue 2016Page 20 of 75
COOLING CAPACITY - 36 (208/230V)
Outdoor
Temperature - °F
(Dry Bulb)
Indoor Temperature - °F (Dry Bulb / Wet Bulb)
65°F / 54°F 70°F / 59°F 75°F / 63°F 80°F / 67°F
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
–13 28.48 25.99 29.62 26.67 30.37 27.58 30.86 28.29
–5 30.31 27.45 30.83 28.06 32.02 28.64 32.55 28.92
0 30.48 27.83 31.70 28.68 32.20 29.10 32.74 29.88
5 31.32 28.03 31.73 28.29 32.52 29.63 33.99 30.40
15 31.35 28.12 32.08 29.21 33.03 30.55 34.10 30.85
25 31.39 28.18 31.83 29.05 33.06 30.67 34.50 30.98
35 31.45 28.58 32.27 29.21 33.52 30.94 35.17 31.42
45 32.09 28.28 33.09 28.90 33.91 30.62 35.27 31.63
55 31.71 28.94 32.40 29.32 33.79 30.79 35.65 31.42
65 30.85 28.34 32.33 29.73 32.81 30.47 34.97 32.32
75 30.67 28.48 31.90 29.24 32.70 30.49 35.08 32.07
85 30.14 27.66 30.80 28.53 31.57 28.99 35.31 32.42
95 29.02 26.72 29.78 27.92 30.53 28.11 36.52 33.35
105 25.83 23.85 26.87 24.35 27.54 25.15 34.07 28.73
110 24.33 22.02 25.08 23.08 26.26 23.83 30.70 26.02
115 23.30 21.44 24.43 22.29 25.04 22.66 29.36 24.22
122 23.05 20.03 23.77 21.10 24.36 22.05 28.94 23.87
HEATING CAPACITY - 36 (208/230V)
Outdoor
Temperature - °F
(Dry Bulb)
Indoor Temperature - °F (Dry Bulb)
60°F 65°F 70°F 75°F
Total
mBtuh
Total
mBtuh
Total
mBtuh
Total
mBtuh
–13 17.74 16.76 15.74 14.74
–5 20.09 19.08 18.08 17.08
0 24.16 23.16 22.16 21.15
5 25.14 24.18 23.14 22.14
17 26.16 25.18 24.12 23.16
19.4 27.96 26.94 24.72 23.78
24.8 30.46 28.23 27.23 26.28
32 31.75 30.70 29.70 28.75
35 34.22 33.22 32.22 31.27
39.2 36.72 34.57 34.78 33.80
44.6 38.10 37.13 36.10 35.13
47 39.49 38.59 37.56 36.49
53.6 39.70 38.73 37.70 36.70
57 39.85 38.88 37.85 36.91
