Allison Transmission 3000

PTO
PROVISION
OUTPUT
SPEED
SENSOR
NAMEPLATE
RIGHT-REAR VIEW
LEFT-FRONT VIEW
INPUT
SPEED
SENSOR
ASSEMBLY PADS
MAIN-PRESSURE TAP
NOTE: Inch Series Threads
BREATHER
FEEDTHROUGH HARNESS
CONNECTOR
COOLER PORTS
NOTE: Inch Series Threads
V07289.02.00
ASSEMBLY PADS
(BOTH SIDES)
BREATHER
MAIN-PRESSURE TAP
NOTE: Inch Series Threads
FEEDTHROUGH HARNESS
CONNECTOR
TORQUE CONVERTER
WITH LOCKUP CLUTCH
AND TORSIONAL DAMPER
PTO PROVISION
(AVAILABLE BOTH SIDES)
Figure 1–6. 3000 Product Family Transmission with PTO
13
