Allison Transmission 3000

ASSEMBLY PADS
(BOTH SIDES)
TO RETARDER
ACCUMULATOR
OIL FILL TUBE
AND DIPSTICK
(AVAILABLE ON
BOTH SIDES
)
OUTPUT
RETARDER
TORQUE CONVERTER
WITH LOCKUP CLUTCH
AND TORSIONAL DAMPER
BREATHER
MAIN-PRESSURE TAP
NOTE: Inch series threads
FEEDTHROUGH
HARNESS
CONNECTOR
RETARDER
VALVE BODY
CONNECTOR
OUTPUT
SPEED
SENSOR
ASSEMBLY PADS
MAIN-PRESSURE TAP
NOTE: Inch Series Threads
BREATHER
COOLER PORTS
NOTE: Inch Series Threads
LEFT-REAR VIEW
LEFT-FRONT VIEW
V07300.01.00
TACHOGRAPH PROVISION
NOTE: Metric Series Threads
SPEEDOMETER PROVISION
NOTE: Inch Series Threads
Figure 1–8. 3000 Product Family Transmission with Retarder and
Provisions for Tachograph and Speedometer
15
