Allison Transmission 3000

TURBINE SPEED
SENSOR
MOUNTING
PAD
SHIPPING
BRACKET (3)
ENGINE SPEED
SENSOR
NAMEPLATE
FILL TUBE
OUTPUT SPEED
SENSOR
FEEDTHROUGH
HARNESS
CONNECTOR
PTO
(TOP RIGHT POSITION)
V07291.00.01
COOLER PORTS
PTO
(BOTTOM LEFT
POSITION)
MAIN-PRESSURE TAP
MOUNTING PAD
(BOTH SIDES)
COOLER PORTS
FEEDTHROUGH
HARNESS
CONNECTOR
RIGHT-REAR VIEW
LEFT-REAR VIEW
Figure 1–10. 4000 Product Family Transmission with PTO
17
