Allison Transmission 3000

V07292.03.00
RIGHT-FRONT VIEW
LEFT-REAR VIEW
PTO (TOP RIGHT POSITION)
RETARDER
FEEDTHROUGH
HARNESS
CONNECTOR
COOLER PORTS
PTO (TOP RIGHT POSITION)
MOUNTING PADS
(BOTH SIDES)
MOUNTING PADS
(BOTH SIDES)
FILL TUBE
TURBINE
SPEED
SENSOR
ENGINE SPEED SENSOR
PTO (BOTTOM LEFT
POSITION)
MAIN-PRESSURE TAP
NAMEPLATE
FEEDTHROUGH
HARNESS
CONNECTOR
RETARDER
SUMP
COOLER
PROVISION
Figure 1–11. 4000 Product Family Transmission with Retarder and PTO
18
