Allison Transmission 3000

V07399.00.02
LEFT-REAR
LEFT-REAR
FEEDTHROUGH
HARNESS
CONNECTOR
C6 ADAPTER
HOUSING
REAR COVER
C6 ADAPTER
HOUSING
SUMP
COOLER
PROVISION
RETARDER
COOLER
PORTS
PTO (TOP RIGHT POSITION)
PTO (TOP RIGHT POSITION)
MOUNTING PADS
(BOTH SIDES)
MOUNTING PADS
(BOTH SIDES)
PTO (BOTTOM LEFT
POSITION)
PTO (BOTTOM LEFT
POSITION)
MAIN-PRESSURE TAP
MAIN-PRESSURE TAP
Figure 1–12. 4000 Product Family 7-Speed Transmission
with PTO (Top) and 7-Speed with PTO and Retarder (Bottom)
19
