Instructions FMA03 26.04.2013 Page 14/21
4.3.2 Table of functions in the SETTING menu
The following table shows the possible functions and values, that can be set or
shown in the SETTINGS menu. The values mentioned in the “default” column are
the standard settings. “X” in the default column means that this function only shows
a value, but cannot be changed.
Function Name Values Default Description
F01 Brightness 1 .. 15 8 To set the brightness of the LED display (15=brightest)
F02 Protocol RS485 0 .. 8 2 Possible protocols: 0, 1, 2, 3, 4, 5, 6, 8
F03 Protocol RS422 0 .. 8 5 Possible protocols 0, 3, 4, 5, 6, 8
F04 Protocol RS232 0 .. 8 6 Possible protocols 0, 3, 4, 5, 6, 8
F05 Protocol USB 0 .. 8 8 Possible protocols 0, 3, 4, 5, 6, 8
0: off, 1: int Bus Slave, 2: int Bus Master, 3: AFL 1.0,
4: ST 2.0, 5: ST old, 6: Kabcom, 7: reserved, 8: In Bus Master V19
F06 Disable IR Receiver on
Cable Connection
0 .. 1 1 0: IR signals of the remote control are accepted when the remote control is
connected to the FMA03 by cable
1: IR signals of the remote control are not accepted when the remote
control is connected to the FMA03 by cable
F07 Enable IR / NFC
Commands
0 .. 3 3 Determines which kinds of remote controls are accepted:
0: only cable,
1: only cable / IR commands,
2: only cable / NFC commands,
3: cable / IR and NFC commands are accepted
Attention: this function may only be changed with a remote control that is
connected to the FMA03 by cable before changing the settings.
F08 Sound Duration 0 .. 3 1 Determines the duration of the acoustic signal.
F09 MC Reset Time 0 .. 3 3 Determines the time until the signalling lamps <1> are reset automatically.
(not yet implemented)
F10 Validated IR FB-Adresse 0..31 X Shows the address (channel) of the actually assigned remote control
F11 NFC Module installed 0 .. 1 X Shows, whether a NFC module is installed
F12 My NFC Adress 0..9999 X Shows My NFC Address
F13 Validated NFC FB-Adresse1 0..9999 X Shows 1st programmable address of a NFC remote control
F14 Validated NFC FB-Adresse2 0..9999 X Shows 2nd programmable address of a NFC remote control
F15 Validated NFC Slave-Adresse1 0..9999 X Shows 1
st
validated address of the FMA 03 Slaves. (0 <=> na)
F16 Validated NFC Slave-Adresse2 0..9999 X Shows 2nd validated address of the FMA 03 Slaves. (0 <=> na)
F17 Validated NFC Slave-Adresse3 0..9999 X Shows 3rd validated address of the FMA 03 Slaves. (0 <=> na)
F18 Status IR Receiver X Shows status of IR receivers:
0: all OK. 1: IR center shut off, 2: IR right side shut off, 4 : IR left side shut
off
F19 Act Fencing Mode 0 .. 3 X Shows selected weapon: 0: Epee, 1: Foil, 2: Sabre, 3: Wireless
F20 Slave Type 0 .. 2 X Shows which kind of Slave this FMA03 is: 0: no Slave, 1: reserved,
2: serial slave
F21 Inverted Display 0 .. 1 X Shows whether display is inverted in Slave mode:
0 = inverted; 1 = normal (not inverted)
F22 Version MC X Shows software version of MC (Machine Core)
F23 Version CC X Shows software version of CC (Communication Controllers)
F24 Hardware MC X Shows hardware version of MC (Machine Core).
F25 Hardware CC X Shows hardware version of CC (Communication Controllers)
F26 Bootloader MC X Shows version of the Bootloader of MC (Machine Core).
F26 Bootloader CC X Shows version of the Bootloader of CC (Communication Controllers)
F28 NFC Pairing 0 .. 3 0 Starts NFC Pairing
2: Tries NFC pairing: 3: Deletes all paired devices
(to be confirmed by “chrono reset” <23>)
F29 Load Default Values 0 .. 2 0 2: Restores the default (standard) values
(to be confirmed by “chrono reset” <23>).
F30 Update Software 0 .. 2 0 2: Starts software update procedure values
(to be confirmed by “chrono reset” <23>).
