Alltion (Guangxi) Instrument Co., Ltd.
AM-2000 User’s Manual | Product Assembly
Installation of Objective Lens
The installation methods for the 200mm objective
lens,250mm objective lens， 300mm objective
lens, 350mm objective lens, 400mm objective
lens and 200-300mm objective lens are the
same.
Mount the large objective (1) into the
microscope mount with two M4 screws (3).
Install the safety screws (2).
Installation of Control handle
Mount the control handle (3) into the
microscope mount with two M4 screws (2).
Installation of Decorative panel（1）.
