Product Functions | AM-2000 User’s Manual
120°Hanger bracket
1 Friction adjustment knob for tilting motion (forwards/backwards) of the
main lens of the microscope
Used to adjust the friction of the pitching rotation of the main lens of the
microscope (as indicated by the arrow on the left).
2 Friction adjustment knob for tilting motion (left/right) of the main lens of the
microscope
Used to adjust the friction of the horizontal tilting movement of the main
lens of the microscope (as indicated by the arrow on the left).
3 Dimming knob
For adjusting the brightness of the illumination, The dimming identification
as the one in the left picture.
