AM-5000 User's Manual | Product assembly
Installation of Objective Lens
The installation methods for the 250mm
objective lens, 300mm objective lens,
400mm objective lens and 198-455mm
objective lens are the same.
Mount the large objective (1) into the
microscope mount with two M4
screws (2).
Installation of Control Handle
Mount the control handle (3) into the
microscope mount with two M4
screws (2).
Installation of Decorative panel（1）.
