Allweiler AEB1E - Quantity; Pump Group; AE1 F and AEB1 F; AE1 L and AEB1 L

Appendix
Lubricant quantities
Values by pump groupParameter
1234
5
6
7
8910
Oil per joint [cm
3
]
4 1018375287169290565885
Grease per bearing
[g]
–
70 135 225 280 530 680 1270 2050 4070
Tab. 35 Lubrication quantities by pump g roup
Volumetric flow rate of sealing medium
Values by pump groupParameter
1234
5
6
7
8910
Volumetric flow rate
[l/min]
–
0.05 0.07 0.09 0.11 0.11 0.15 0.21 0.27 0.78
Tab. 36 Volumetric flow rate of sealing medium by pump group
9.2.10 Total volume and residual liquid quantity
AE1F and AEB1F
Values by size [l]Parameter
103 203 403 553 703 1003 1603 3003 5503
Totalvolume 1.302.254.126.957.4111.6613.1725.5849.12
Residual liquid quantity 0.35 0.65 1.18 1.68 2.02 2.88 4.01 7.69 13.94
Tab. 37 Total volume and residual liquid quantity AE1F and A EB1F
AE1L and AEB1L
Values by size [l]Parameter
51 101 201 381 551 751 1001 1451 2701 5001
Total volume 1.18 1.30 2.24 4.07 6.98 7.45 12.2 2 12.8 7 24.60 47.82
Residual liqui d quantity 0.26 0.35 0 .65 1.15 1.70 2.05 3.30 3.78 6.96 12.95
Tab. 38 Total volume and residual liquid quantity AE1L and AEB1L
AE1E and AEB1E
Values by size [l]Parameter
50 100 200 380 550 750 1000 1450 2700 5000
1)
9500
1)
Total volume 1.19 2.06 3.62 6.49 6.95 11.17 11.66 21.65 42.26 69.03 128.66
Residual liquid quantity 0.25 0.46 0.81 1.33 1.68 2.51 2.88 4.75 8.78 16.28 28.89
Tab. 39 Total volume and residual liquid quantity AE1E and AEB1E
1) Applies only for AE1E
AED1E
Values by size [l]Parameter
75
150 300 560 1200 2300 4250 7800 15500
T
otal volume
1
.26
2
.20
3
.89
6
.98
1
2.22
2
3.67
4
6.00
7
5.81
1
42.23
Residual liquid quantity 0.31 0.57 1.01 1.70 3.30 6.26 11.59 21.36 39.06
Tab. 40 Total volume and residual liqui d quantity AED1E
