Allweiler SPF series - 9 Appendix; Sectional Drawings; Part Numbers and Designations; Designation of Components According to Part Numbers

Appendix
9 Appendix
9.1 Sectional drawings
9.1.1 P art numbers and designations
Part no. Designation
1 Pump casing
2
1)
Casing insert
3 Pump cover, drive end
4 Pump cover, end si de
7
Housing cover
9 Filter housing
10
1)
Bush
12
1)
Drive spindle
13
1)
Idler spindle
20
Spacer sleeve
24
Socket head cap screw
29 Pipe
30 Pipe
100
1)
Seal
119
1)
O-ring
120
1)
O-ring
122
1)
O-ring
142
1)
Seal ring
143
1)
Seal ring
146
1)
Seal
151
1)
Seal ring
152
1)
Seal ring
156
1)
Seal ring
157
1)
Seal ring
159
1)
Seal ring
160
Sealing plug
186
1)
Mechanical seal
200
Socket head cap screw
201
Socket head cap screw
207 Hexagon head bolt
Part no. Designation
215
3)
Socket head cap screw
216
3)
Hexagon head bolt
217
3)
Hexagon head bolt
222
Screw plug
223 Bleeding plugs
227
Screw plug
231
3)
Hexagon nut
235
Screw plug
250
Snap ring
251
Snap ring
263
Supporting washer
280 Blind rivet
290 Key
292
1)
Ball bearing
330
1)
Valve cone
331
Spring retainer
333 Adjusting screw
340
1)
Spring
361 Pressure gauge
362 B allcock
364
Connecting piec e
460
3)
Bell housing
471
3)
Mounting foot
481
Screen fi
lter
90
0
3)
Pump-side coupling half
901
3)
Motor-side coupling half
910
3)
Motor
962
4)
Heating shell with strap
970 Rating plate
978 DIN test plate
Tab. 13 Designation of components according
to part numbers
1) Can be ordered as spare part/spare part kit
2) Possibly not shown
