Alpha ESS SMILE5 - Page 29

Product Introduction and Application Scenarios
27
Connection area overview of SMILE5-BAT and SMILE-Bat-5.8P
Position
Designation
1
Battery+ Power Connector
2
Battery- Power Connector
3
Grounding
4
BMS COM Ports
5
Battery Power Button
6
Battery Breaker
7
Battery LED Display
Connection area overview of SMILE-Bat-10.1, SMILE-Bat-10.3, SMILE-Bat-13.3P.
*Only SMILE-Bat-13.3P has one pair of battery power ports.
