Operation
16
(06/2016)
Control Parameters
See the gure below for the scope of the parameters that are available on the Control Parameters page.
Figure 12, Control Parameters Screens
Table 4, Control Parameters
Batt. Type
Sealed
Batt. AH
200AH
Temp Comp. Coe
-3mv/°C/2V
Rated Voltage
12V
Over Volt. Disc
16.0V
Charge Limit
15.0V
Over Volt. Rec.
15.0V
Equal. Charge
14.6V
Boost Charge
14.4V
Float Charge
13.8V
Boost Rec.
13.2V
Low Volt. Rect.
12.6V
Under Volt. Rect
12.2V
Under Volt. Warn
12.0V
Low Volt. Disc
11.1V
Discharge Limit
10.6V
Equalize Time
120min
Boost Time
120min
Control Parameters
Parameters Default Range
Battery Type Sealed Sealed/Gel/Flooded/User
Battery Ah 200Ah 1~9999Ah
Temperature Compensation Coecient -3mv/°C/2V 0~9mv
Rated Voltage Auto Auto/12V/24V/36V/48V
