Load Setting
The Load Setting page is used to set the four load working modes of the charge controller:
1. Manual
2. Light On / O
3. Light On+ Timer
4. Time Control
Figure 13, Load Setting Screens
Table 6, Manual Control
Manual Control
Light On/O
Light On+ Timer
Time Control
Manual Control
Light On/O
Light On+ Timer
Time Control
Manual Control
Light On/O
Light On+ Timer
Time Control
Manual Control
Light On/O
Light On+ Timer
Time Control
Manual Control
Default: On
Light On/Off
On 05.0V DeT 10M
Off 06.0V DeT 10M
Light On+ Timer
On 05.0V DeT 10M
On 06.0V DeT 10M
NightTime 10H:00M
Time Control
Time1
OnTime 10:00:00
OffTime 19:00:00
Light On+ Timer
OnTime1 01H:00M
OnTime2 01H:00M
√
√
√
√
Time Control
Time2
OnTime 19:00:00
OffTime 19:00:00
Manual Control
Mode Function
On
The load is on, and will stay on, given that the battery capacity is sucient and there are no abnormal
conditions.
O The load is o.
