Battery Voltage Parameters
Table 5, Battery Voltage Parameters
Battery Voltage Parameters
Battery Charging Setting Sealed Gel Flooded User
Over Voltage Disconnect Voltage 16.0V 16.0V 16.0V 9~17V
Charging Limit Voltage 15.0V 15.0V 15.0V 9~17V
Over Voltage Reconnect Voltage 15.0V 15.0V 15.0V 9~17V
Equalize Charging Voltage 14.6V -- 14.8V 9~17V
Boost Charging Voltage 14.4V 14.2V 14.6V 9~17V
Float Charging Voltage 13.8V 13.8V 13.8V 9~17V
Boost Reconnect Charging Voltage 13.2V 13.2V 13.2V 9~17V
Low Voltage Reconnect Voltage 12.6V 12.6V 12.6V 9~17V
Under Voltage Warning Reconnect Voltage 12.2V 12.2V 12.2V 9~17V
Under Voltage Warning Voltage 12.0V 12.0V 12.0V 9~17V
Low Voltage Disconnect Voltage 11.1V 11.1V 11.1V 9~17V
Discharging Limit Voltage 10.6V 10.6V 10.6V 9~17V
Equalize Duration 120min -- 120min 0~180min
Boost Duration 120min 120min 120min 0~180min
The parameters in the table below are from a 12V system at 25°C. Multiply this by 2 in 24V systems, 3 in
36V systems, and 4 in 48V systems.
Notice
» When the battery type is sealed, gel, or ooded, the adjusting range of the equalize duration is 0
to 180min and the boost duration is 10 to 180min.
» The following conditions must be observed when modifying the parameters for the user battery
type:
» Over Voltage Disconnect Voltage > Charging Limit Voltage ≥ Equalize Charging Voltage ≥
Boost Charging Voltage ≥ Float Charging Voltage > Boost Reconnect Charging Voltage
» Over Voltage Disconnect Voltage > Over Voltage Reconnect Voltage
» Low Voltage Reconnect Voltage > Low Voltage Disconnect Voltage ≥ Discharging Limit
Voltage
» Under Voltage Warning Reconnect Voltage > Under Voltage Warning Voltage ≥ Discharging
Limit Voltage
» Boost Reconnect Charging Voltage > Low Voltage Disconnect Voltage.
Notice
