Set decrease / increase
Decrease Heating Temperature dierence in K for heating
circuit in operating state 2
Increase heating
Temperature dierence in K for heating
circuit in operating state 4
Increase SW
Temperature dierence in K for
domestic hot water heating in
operating state 4
NOTE
Priority controlling is still retained in Smart Grid operation.
Return ow limitation temperature (return ow limitation)
and ow maximum are also monitored in Smart Grid op-
eration.
Terminal diagrams Smart Grid
Klemmenplan SG-Ready IO-Max
-
a
-X4
-X5
SG1
SG2
Legende:
Betriebsmittel
A1
A3
SG1
SG2
IN5
IN6
DE
Funktion
Reglerplatine; Achtung: I-max = 6,3A/230VAC
Unterverteilung Hausinstallation
Smart Grid Ansteuerung 1
Smart Grid Ansteuerung 2
831211a
123 45678
12 8
A
B
C
D
E
F
A
B
C
D
E
F
Blatt
Bl.
1
1
34567
AIT
831211
Klemmenplan
ait-deutschland GmbH
ÄM999/2019
08.10.2019
AP
L1 L1 L1 L
2
2
IN1 IN2 IN3A1A2A1A2
IN4 IN5 IN6 IN7
A3
A1
Änderung Datum
Datum
Bearbeiter
Geprüft
NormName
09.10.2015
Pfleger
R.
Klemmenplan SG-Ready IO-Max
-
a
-X4 -X5
SG1
SG2
Legend:
Equipement
A1
A3
SG1
SG2
IN5
IN6
UK
Function
Controller board; Attention: I-max = 6,3A/230VAC
Sub-distribution unit internal installation
Smart Grid activation 1
Smart Grid activation 2
831211a
12345678
12 8
A
B
C
D
E
F
A
B
C
D
E
F
Blatt
Bl.
1
1
34567
AIT
831211
Klemmenplan
ait-deutschland GmbH
ÄM999/2019
08.10.2019
AP
L1 L1 L1 L
2
2
IN1 IN2 IN3A1A2A1A2
IN4 IN5 IN6 IN7
A3
A1
Änderung Datum
Datum
Bearbeiter
Geprüft
NormName
09.10.2015
Pfleger
R.
