ACKNOWLEDGING A FAULT
If a fault occurs and an error message appears in the screen, then:
1. Notice error number.
2. Acknowledge error message by pressing the “rotary push-
button“ (for 7 seconds).
The screen changes from the error message to the naviga-
tion screen.
3. If this error message occurs again, contact the tter or au-
thorised service personnel (= customer service),
if the error message prompted you to do this. Communicate
error number and arrange further procedure.
FLASHING CODES ON CONTROLLER BOARD
Green LED ashes every second everything ok
Red LED ashes briey for short Data being received over LIN
bus
Green and red LED light up The board can receive a
software update
During the software update the green LED is lit and the red one
ickers quickly
Technical Data
INSTALLATION
Only in frost-free, dry and weatherproof rooms.
Ambient temperature: 0 °C – 35 °C
Electrical connection: 230 V AC, 18 VA, 0.1 A
(max. power consumption regulator
without any appliances connected)
Fuse: 1.6 A (
transformer)
OUTPUTS
Relay contacts: 8 A / 230 V,
Fuse: 6.3 A (for all relay outputs)
In total consumers up to 1,450 VA can be connected to the out-
puts
INPUTS
Optocoupler: 230 V
Sensor inputs: NTC sensor 2.2 kΩ / 25 °C
CONNECTIONS
Control line: 12-pole, outputs 230 V
Sensor line: 12-pole, low voltage
Plug-in terminals: 1-pole, screw terminals
INTERFACES
USB: USB version 2.0 (USB 2.0)
Host, A plug (only for a USB stick!)
Ethernet: 1 x 10 Base-T / 100 Base-TX
(RJ-45, plug, bent)
PROTECTION CLASS
Protection class IP 20
TEMPERATURE SENSOR CHARACTERISTIC CURVE
t / °C R / kΩ
-25 21.291
-20 16.425
-15 12.773
-10 10.010
-5 7.903
+/-0 6.284
+5 5.030
+10 4.053
+15 3.287
+20 2.681
+25 2.200
+30 1.815
+35 1.505
+40 1.255
+45 1.051
+50 0.885
+55 0.748
+60 0.636
+65 0.542
+70
0.464
+75
0.399
+80
0.345
+85
0.299
+90
0.260
+95
0.227
+100
0.198
+105
0.174
+110
0.153
+115
0.136
+120
0.120
+125
0.106
+130
0.095
+135
0.085
+140
0.076
