Alpha-InnoTec Luxtronik User Manual

45Subject to technical amendments without prior notice | 83055400iUK – 2.1 | ait-deutschland GmbH
SENSOR MEASURING RANGE
Type of sensor Measuring range
Autom. value in case of
sensor defect
PEX -40°C to 40°C -
TA -50°C to 90°C -5 °C
TBW -45°C to 155°C 75 °C
TFB1 -20°C to 150°C 75 °C
TRL ext -40°C to 40°C 5 °C
TVL 0°C to 100°C 5 °C
TVL2/TEH 0°C to 100°C 5 °C
TRL 0°C to 100°C 5 °C
Extension
board
TSS -20°C to 140°C 150°C
TSK -20°C to 140°C 150°C or 5°C
TB2 0°C to 100°C 75°C
TB3 0°C to 100°C 75°C
TEE 0°C to 100°C 5°C
OVERVIEW: DEFROST CYCLE, AIR DEFROST, FLOW MAX
Defrost cycle Air defrost Flow Max
from / end flow Max. min. AT flow max. low limit of applic.
LW 160H(A)V 45 – 65 -15 60
LW 161H(A)V variable – 65 -15 60
Paros 4 variable – 65 2 45
LWV 82R1/3 variable – 60 -5 45
LWV 122R3 variable – 60 -5 45
LWAV 82R1/3 variable – 60 -5 45
LWAV 122R3 variable – 60 -5 45
LWAV+ 82R1/3 variable – 60 -5 45
LWAV+ 122R3 variable – 60 -5 45
LWCV 82R1/3 variable – 60 -5 45
LWCV 122R3 variable – 60 -5 45
LWP 450AR3 60 – 65 -10 60
LWDV variable – 70 -7 60
