Alpha-InnoTec Luxtronik User Manual

47Subject to technical amendments without prior notice | 83055400iUK – 2.1 | ait-deutschland GmbH
Parameter Factory setting
Adjustment during
commissioning *)
Value range (adjustable steps) Access
low limit of applic.
L/W: device-dependent
LDWV: 62 °C
S/W & W/W: 52 °C
°C 35 °C – 75 °C (↕1) AS
hysteresis cool.contr
L/W: 3.0 K
S/W: 2.0 K
1 K – 5.0 K (↕0.5)
Fitter
service water max 65 °C °C 30 °C – 65 °C (↕0.5)
Fitter
min.systemtemp. 15 °C °C 15 °C – 30°C (↕0.5)
User
Defrost end temperature 45 °C
35 °C – 45 °C (↕1)
LW161HAV / LW161HV: 35 °C – 50 °C (↕1)
AS
minimal ow mc 1 20 °C °C 20 °C – 40 °C (↕1)
Fitter
maximum ow mc 1 45 °C °C 25 °C – 75 °C (↕1)
Fitter
Hysteresis 2.CP short 4.0 K K 2 – 6 (↕1)
Fitter
desuperheater max. 65 °C °C 30 °C – 75 °C (↕1)
Fitter
min. ow cooling 18 °C °C 18°C – 25 °C (↕1)
Fitter
min. ow cooling 2CP 10 °C °C 7 °C – 20 °C (↕1)
Fitter
System settings
El. sup. blockade no 2hg no 2hg • with 2hg
Fitter
Roomstat. No No • RBE • Smart
User
Integration Return Return • Sep. tank
Fitter
Mixing circ 1 No no • charge • discharge • cool • heat+cool
Fitter
Error no 2hg
no 2hg • Heating • DHW • with 2hg Fitter
Service water 1 sensor sensor • Thermal
User
Service water 2 CP CP • h.wCP
Fitter
Service water 3 with CP wo. CP • with CP
Fitter
Service water 4 set value set value • Max
Factory
Service water 5 device-dependent wo HSP • with HSP • par HUP
Fitter
SW+HP max 0 h 0 h – 8 h (↕0.5)
User
Defr cycle max 45 min 45 • 60 • 75 • 90 • 120 • 180 • 240 min
Fitter
Defrost. Air No No • Yes
AS
Defr.Air max 15 min 5 min – 30 min (↕1)
AS
pump opt. Yes No • Yes
User
Access AS Fitter • AS
AS
brine pres/Flow device-dependent
No • ow • Brine pres •
pow.suppl. • pow.+ow
AS
Control CP On O • On
AS
setting hc Set AT Set AT • Fixed Tp
Fitter
setting mc1 Set AT Set AT • Fixed Tp
Fitter
Cooling Fixed Tp Set AT • Fixed Tp
User
screed heating w. mixer wo. mixer • w. mixer
User
El. Anode device-dependent No • Yes
AS
Heating limit Yes No • Yes
User
parall. operation No No • Slave • Master
Fitter
remote maintenance No No • Yes
User
pump optim. Time 180 min 5 – 180 min (↕5)
User
ow VBO 1 min 1 – 5 min (↕1)
Fitter
min defrost cycle 45 min 45 • 60 • 90 • 120 • 180 • 240 • 300
Factory
time 2.CP short 20 min 5 – 20 min (↕1)
Fitter
*) Please enter the adjusted values. Mark not applicable with — .
