6 Installation and connection
6.1 Dismantle the module box
IMPORTANT
If the module box is tilted by more than 45°,
compressor oil runs into the cooling circuit.
Do not tilt the module box by more than 45°.
NOTE
If necessary the module box can be
dismantled for easier transport of the unit
or for service reasons.
Steps 1 to 5 are only required if the module
Unit is safely disconnected from the power supply
again.
1. Remove the front panel of the module
box ( “7.1 Remove the front panel of
the module box”, page 17).
2.
3.
heating.
NOTE
The hose connectors are not part of the
scope of delivery with all KFE ball valves.
Unit without cooling:
Unit with cooling:
4.
heat source (behind the covers).
5.
heat source.
Unit without cooling:
