17
Subject to change without notice | 83057000jUK – Translation of the original operating manual | ait-deutschland GmbH
5. Use cable ties (
in front of the connector (strain relief).
200 mm
6. Push the cable through the opening in the front
panel of the unit from below and into the control.
7. Press the lugs of the control into the openings in
the front panel of the unit.
Mount the control on the wall and connect
IMPORTANT
only ver-
tically on a wall!
1.
2.
of the control (are only needed to insert in the
front panel).
3. Dimensional drawing “Wall-
4.
the web at the bottom in the middle of the wall
5. (②) with 2 wall
plugs (①) and 2 screws (③).
6. Feed in the cables from the wall (e.g. in-wall box)
or from below.
7. Route the LIN bus cable from the top right-hand
side at the rear from the heat pump and plug into
the control at the bottom.
8.
9.
(accessories).
7
7.1 Remove the front panel of
the module box
Unscrew the front panel of the module box.
7. 2
Frost protection must be provided in the heat source.
Below are the approved antifreeze agents based on:
Monopropylene glycol
Monoethylene glycol
Ethanol
Methanol
Antifreeze agents based on salt are not permitted.
