POWER
Series 800
The Series 800 TEC Controller has five (5) standard output power ratings:
10 A @ 15 VDC150 Watts
8 A @ 15 VDC120 Watts
6 A @ 15 VDC90 Watts
4 A @ 15 VDC60 Watts
2 A @ 15 VDC30 Watts
Series 850
The Series 850 TEC Controller has six (6) standard output power ratings
20 A @ 15 VDC300 Watts
10 A @ 15 VDC150 Watts
8 A @ 15 VDC120 Watts
6 A @ 15 VDC90 Watts
4 A @ 15 VDC60 Watts
2 A @ 15 VDC30 Watts
Power Booster Module
Alpha Omega Instruments has gone beyond the conventional approach to powering
TECs by developing a unique Power Booster Module for each of its TEC controllers.
Users can increase the output power of their Series 800 / 850 TEC Controller by
adding one or more Series 800 or 850 Power Booster Modules. Depending upon the
number of Power Booster Modules added, the output power of the controllers can be
doubled, tripled, or even quadrupled. The additional power available through the
Power Booster Modules can go into the kilowatts. And, regardless of the number of
booster modules used, they along with the controllers, are driven from one
temperature sensor, thus ensuring uniform temperature control. The Series 800 and
850 Power Booster Modules can be easily installed in the field.
ALPHA OMEGA INSTRUMENTS CORP. Instruction Manual
Series 800/850 Thermoelectric Cooler Controller Page 8
