SOFTWARE MAP
ALPHA OMEGA INSTRUMENTS CORP. Instruction Manual
Series 800/850 Thermoelectric Cooler Controller Page 68
Navigation
Software Map
Note: What you see depends on the options and settings included in your controller.
Note: For easy reference to prompts on the Operations and Setup pages, unfold the inside back cover flap while you read
through the parameters in Chapter Six.
[Mon]
Monitor Menu
[OPEr]
Operations Page
[OPEr]
Operations Page
[Pr2`]
Process 2
[Pcnt]
Percent Output
[rPSP]
Ramping Set Point
[E`St]
Event Input Status
[OPEr]
Operations Page
[A-M]
Auto-Manual Operation Mode
[`Aut]
Auto-tune
[AtSP]
Auto-tune Set Point
[`SP2]
Set Point 2
[E`SP]
Event Set Point
[`L-r]
Local or Remote Mode
[CAL1]
Calibration Offset
[OPEr]
Operations Page
[Pb`1]
Propband 1
[It`1]
Integral 1
[rE`1]
Reset 1
[dE`1]
Derivative 1
[rA`1]
Rate 1
[brS1]
Burst 1
[Ct`1]
Cycle Time 1
[hYS1]
Hysteresis 1
[db`1]
Dead Band 1
[OPEr]
Operations Page
[Pb`2]
Propband 2
[It`2]
Integral 2
[rE`2]
Reset 2
[dE`2]
Derivative 2
[rA`2]
Rate 2
[brS2]
Burst 2
[Ct`2]
Cycle Time 2
[hYS2]
Hysteresis 2
[db`2]
Dead Band 2
[OPEr]
Operations Page
[A2Lo]
Alarm 2 Low
[A2hi]
Alarm 2 High
[A3Lo]
Alarm 3 Low
[A3hi]
Alarm 3 High
[A4Lo]
Alarm 4 Low
[A4hi]
Alarm 4 High
‰
‰
‰
‰
‰
¿
¿
¿
¿
[USEr]
User Menu
[OPEr]
[Pid1]
PID 1 Menu
[OPEr]
[PiD2]
PID 2 Menu
[OPEr]
[ALM]
Alar m Me nu
[OPEr]
¯
¯
¯
¯
[``96]
Process 1 Value
[``96]
Set Point Value, Remote Set Point Value, Event Set Point,
or Percent Output Value
[``96]
Custom Menu…
[``P1]
Parameter selection 1
[Mon]
Monitor Menu
[OPEr]
Operations Page
[InP1]
Input 1 Menu
[`SEt]
Setup Page
[CUSt]
Custom Menu
[FctY]
Factory Page
Home Page
‰
¿ and ¯
for 3 seconds
Operations Page
Setup Page
Factory Page
¿ and ¯
for 3 seconds
‰ and ˆ
for 6 seconds
¯ or ¿ to cycle through menus
‰ to select a parameter in a menu
¯ or ¿ to select a value
‰ to enter a value and go to the next parameter
ˆ anytime to return to the Home Page
‰ at Home Page to view Custom Menu
