SCREEN 2
INSTALLATIONS DATA: ALPHAVISION NG v1.1 -- date
IO01 IO02 IO03 IO04 IO05 IO06 IO07 IO08 IO09 IO10 IO11 CP DC
Burglary A 19 .. .. .. .. .. .. .. .. .. .. 019 00
Burglary B 19 .. .. .. .. .. .. .. .. .. .. 019 00
Burglary C 19 .. .. .. .. .. .. .. .. .. .. 019 00
Burglary D 19 .. .. .. .. .. .. .. .. .. .. 019 00
Burglary E 19 .. .. .. .. .. .. .. .. .. .. 019 00
Burglary F 19 .. .. .. .. .. .. .. .. .. .. 019 00
Burglary G 19 .. .. .. .. .. .. .. .. .. .. 019 00
Burglary H 19 .. .. .. .. .. .. .. .. .. .. 019 00
Sabotage A 20 .. .. .. .. .. .. .. .. .. .. 200 00
Sabotage B 20 .. .. .. .. .. .. .. .. .. .. 200 00
Sabotage C 20 .. .. .. .. .. .. .. .. .. .. 200 00
Sabotage D 20 .. .. .. .. .. .. .. .. .. .. 200 00
Sabotage E 20 .. .. .. .. .. .. .. .. .. .. 200 00
Sabotage F 20 .. .. .. .. .. .. .. .. .. .. 200 00
Sabotage G 20 .. .. .. .. .. .. .. .. .. .. 200 00
Sabotage H 20 .. .. .. .. .. .. .. .. .. .. 200 00
In screen 2 you can program which outputs are activated for each event (e.g. burglary), for each section. In
the screen above you can see that outputs 1 and 9 of the first I/O module and outputs 1 and 9 of the control
panel in case of a burglary alarm in sections A to H. In this case output 1, which is the relay output, and
output 9, which is the speaker output, of both the first I/O module and of the control panel are activated.
Example: when in case of a burglary alarm in section E outputs 3 and 4 of the I/O module and outputs 5, 6
and 7 of the control panel must be activated, the programmed line should be:
Burglary E 34 .. .. .. .. .. .. .. .. .. .. 567 00
For each event you can decide per section which outputs of which I/O modules and control panel are
activated. For each I/O module you can program up to 2 outputs for each event and for the control panel you
can program 3 outputs to be activated. How long the outputs are activated is programmed in screen 8, see
also page 43.
For Tamper events (sabotage) a difference between an armed and a disarmed section is made. The left
number at the I/O modules and the two left numbers at control panel represent the outputs activated in case
of a tamper alarm when the section is armed, and the right numbers at the I/O modules and at control panel
represent the outputs activated in case of a tamper alarm when the system is disarmed.
Sabotage D 12 .. .. .. .. .. .. .. .. .. .. 345 00
So, in the above example a tamper alarm in section D when the section is armed will activate output 1 of the
first I/O module and outputs 3 and 4 of the control panel, and a tamper alarm when section D is disarmed
will activate output 2 of the I/O module and output 5 of the control panel.
For each type of event a dial code (DC) can be programmed. When the reports are send with the SIA or SIA-
HS protocol this column has no meaning, with the other protocols the dial code must be programmed for
each type of event. For more information, see page 46.
Programming screen 3 to 6 is done in the exact same way as programming screen 2.
AlphaVision NG installation manual Rev. 2.0 27-08-2003 Blz. 42/101
