4.2ch (FRONT'REAR'SUBW.) System
F-L
(Initial
selting)
~
F-R
~
R-L
~
R-R
~
(Front-L) (Front-R) (Rear-L) (Rear-R)
SW-L
~
SW-R
~
F-L
(Front-L)
Adjusting
the
TIme
Correction
Before perfonning the following procedures. refer to "About Time
Correction" (page
34).
I After selecting Time Correction from the Sound Field
Adjustment mode, press
BAND to select a speaker
to be adjusted.
R-L
~
R-R
~
(High-L)
(High-R)
2.2ch (3WAY) System
F-L
(Initial selting)
~
F-R
~
(Mid-L) (Mid-R)
SW-L
~
SW-R
~
F-L
(Mid-L)
2 Turn the
Rotary
encoder
to adjust the distance
(0.0 to 336.6cm).
L
~
(distance
to farthest speaker) - (distance to other
speakers)
Refer to "Time Correction Value List" on
page
34.
3 Repeat steps 1 and 2 to set another speaker.
By setting these values to
make
its sound reach the
listening position at the same time as the
sound
of
other
speakers.
Sound Field Adjustment
Adjusting the Parametric Equalizer
Curve
You can modify the Equalizer settings to create a response curve more
appealing to your personal taste. To adjust the Parametric Equalizer
Curve. set the EQ mode to Parametric EQ. For details. refer to "Setting
EQ mode" (page
31).
I After selecting Parametric EQ from the Sound Field
Adjustment mode, press
BAND to select the band to
be adjusted.
Band1
~
Band2
~
Band3
~
Band4
~
BandS
~
Band1
2 Press
~
or
~
to select frequency bands.
Adjustable frequency bands:
20
Hz
to 20
kHz
(in
1/3 octave steps)
Band-1:
20
Hz-80
Hz
(63 Hz)
Band-2:
50
Hz-200
Hz (150 Hz)
Band-3: 125
Hz-3.2
kHz (400 Hz)
Band-4: 315
Hz-8
kHz
(1
kHz)
Band-5: 800
Hz-20
kHz (2.5 kHz)
3 Turn the
Rotary
encoder
to adjust the level.
Adjustable level:
-6
to +6 dB
4 Press
SOURCE/<!>
to set the bandwidth (Q).
Adjustable bandwidth:
1,
1.5,3
5
To
adjust another band, repeat steps 1 to 4 and
adjust all bands.
The
setting
of
Parametric EQ/Graphic EQ Adjustment. Time Correction
and X-Over can be adjusted
in
this mode.
• The frequencies
of
adjacem bands cannot be adjusted within 4
~'feps.
• While adjusting the Parametric EQ, you should consider the
frequency response
of
the connected speakers.
Adjusting
the
Crossover Settings
Before perfonning the following procedures, refer to "About the
Crossover" (page 35).
Adjusting
the
Graphic Equalizer
Curve
You
can modify the equalizer settings to create a response curve more
appealing to your personal taste. To adjust the graphic equalizer curve.
set the EQ mode to Graphic EQ. For details. refer to "Setting EQ mode"
(page
31).
I After selecting Graphic EQ from the Sound Field
Adjustment mode, press
BAND to select the band to
be adjusted.
Band1
~
Band2
~
Band3
~
Band4
~
BandS
~
Band6
~
Band?
~
Band 1
Band-1 (63 Hz) / Band-2 (150 Hz) / Band-3 (400 Hz) /
Band-4
(1
kHz) / Band-5 (2.5 kHz) I Band-6
(63
kHz) I
Band-? (17.5 kHz)
2 Turn the
Rotary
encoder
to adjust the level.
Adjustable output level: -6
to
+6 dB
3
To
adjust another band, repeat steps 1 and
2,
and
then adjust all bands.
2.2ch (3WAYj System
I After selecting X-Over from the Sound Field
Adjustment mode, press
BANDto select the band to
be adjusted.
2.2ch (3WAY)
System'
NORMAL (L=R)
Setting Items:
LOW
I MID-L I MID-H / HIGH
2.2ch (3WAY) System
'INDIVIDUAL
(UR)
Setting Items:
LOW-L I
LOW-R
/ MID-L-L / MID-L-R / MID-H-L /
MID-H-R / HIGH-L
I HIGH-R
2 Press
~
or
~
to select the desired cut-off frequency
(Crossover Point).
Adjustable frequency bands:
2.2ch (3WAY) System
Setting items:
LOW
/ MID-L
20
Hz-200
Hz
MID-H
20
Hz-20
kHz
HIGH
(1
kHz-20
kHz)*I/(20
Hz-20
kHz)*2
*1
When Maker's is selected, reter
to
"Setting the Response Slope
for
? the High Range Speaker (TW Setupi" (page 31
i.
*-
When User's is selected. reter w"Setting the Response Slope
for
the
High Range Speaker
(TW
Setup)" (page 31).
32-EN
To Next Page
