3 Press SOURCE/<!> to adjust the slope.
Adjustable slope: FLAT*, 6 dB/oct.,
12
dB/oct.,
18
dB/oct.,
24 dB/oct.
* FLAT can be set
for
the HIGH slope only when User's is selected
in
"Setting the Response Slope
for
the High Range Speaker
(TW
Setup)" (page 31). Depending on the response characteristics
of
the .\peaker, care should be taken when setting the response slope to
FLAT. as speaker damage may result.
With
this unit, a message is
displayed when the response
s-[ope
for
the high range speaker is set
to
FLAT.
4 Turn the
Rotary
encoder
to adjust the output level.
Adjustable output level: -12 to 0 dB.
5 Repeat steps 1 to 4 to make adjustment to the other
bands.
4.2ch (FRONT/REAR/SUSW.) System
1 After selecting X-Over from the Sound Field
Adjustment mode, press
BAND to select the band to
be adjusted.
4.2ch
(FRONTIREARlSUBW.) System / NORMAL
(l=R)
Setting items:
LOW (SUB-W) / MID (REAR) / HIGH (FRONT)
4.2ch
(FRONTIREARlSUBW.)
System
/INDMDUAL
(LIR)
Setting items:
LOW (SUB-W)-L I LOW (SUB-W)-R / MID (REAR)-L /
MID (REAR)-R / HIGH (FRONT)-L / HIGH (FRONT)-R
2 Press.... or
~
to select the desired cut-off frequency
(Crossover Point).
Adjustable frequency bands:
4.2ch (FRONT/REARlSUBW.) System
Setting items:
20
Hz-200
Hz
3 Press SOURCE/<!> to adjust the slope.
Adjustable slope:
FLAT,
6 dB/oct.,
12
dB/oct.,
18
dB/oct.,
24 dB/oct.
4 Turn the
Rotary
encoder
to adjust the output level.
Adjustable output level: -12 to 0 dB.
5 Repeat steps 1 to 4 to make adjustment to the other
bands.
• While udjusting the X-oller, you should co/Uider the frequency
response
of
the connected speakers.
• AbOltf the 2.2ch (3WAY)/4.2ch (FRONTIREARISUBW.j system
You
can switch to 2.2ch (3WAY)14.2ch (FRONTIREARISUBW.;
system mode with the 2.2ch (3WAY)14.2ch (FRONTIREARISUBW.)
.\witch on the PXA-H100.
For
details, refer to the Owner's
Mwuwl
of
PXA-HI00.
Storing the Sound Field Adjustment Settings
The Sound Field Adjustment Settings containing Parametric EQ/
Graphic EQ Adjustment. Time Correction and X-Over settings can be
stored
in
the preset memory.
1 When the settings of Sound Field Adjustment have
been completed, select
anyone
of
the
preset
buttons
(1
through
6)
in
any item
of
the Sound
Field adjustment mode (e.g. X-Over), press and hold
the desired preset buttons for at least 2 seconds.
2 Turn the
Rotary
encoder
to select PROTECT
YES/NO, and then press
~/ENT
to store the
adjusted contents.
PROTECT
YES
(Initial setting) H
PROTECT
NO
•
(f
YES is selected, the adjusted contents are protected and stored into
the preset buttons. When you want to store the parameter into a
protected preset button, "Replace NOIYES" can be selected.
•
!f
NO is selected, the preset is stored.
• While perform this operation, all adjusted contents
of
Parametric
EQIGraphic EQ, Time Correction and X-Oller will be stored in the
preset buttons.
• The stored contents are not deleted ellen when resetting the unit
or
disconnecting the battery.
• The stored contellls
ClIn
be recalled by perjorming operation in
"Recalling the Stored Sound Field Adjustmelll Settings" (page 33).
Recalling the Stored Sound Field Adjustment
Settings
The stored Sound Field Settings contain Parametric EQ/Graphic EQ
Adjustment, Time Correction and X-Over settings that are stored
in
the
preset memory.
1 After selecting any item of the Sound Field
Adjustment mode (e.g. X-Over), press
anyone
of the
preset
buttons
(1
through
6)
that has your
desired characteristic
in
memory to recall the stored
settings.
2 Press the
preset
buttons
again to return to the
Sound Field Adjustment mode.
• While performing this operation, all adjustmelll Con/elliS
of
Parametric EQIGraphic
EQ,
Time Correction
and
X-Oller stored
in
the preset buttons will be recalled.
33-EN
