Alpine CDE-W265BT User Manual

39-EN
iPod nano (5th generation): Ver.1.0.2
iPod classic (160 GB) (Late 2009): Ver.2.0.4
iPod touch (2nd generation): Ver.4.2.1
iPod nano (4th generation): Ver.1.0.4
iPod classic (120 GB): Ver.2.0.1
iPod touch (1st generation): Ver.3.1.3
iPod nano (3rd generation): Ver.1.1.3
iPod classic (80 GB, 160 GB): Ver.1.1.2
• The following devices have been certified following Made for iPhone
guidelines. Correct function of earlier versions cannot be guaranteed.
iPhone 5s: Ver.7.1.1
iPhone 5c: Ver.7.1.1
iPhone 5: Ver.7.1.1
iPhone 4s: Ver.7.1.1
iPhone 4: Ver.7.1.1
iPhone 3GS: Ver.6.1.6
iPhone 3G: Ver.4.2.1
iPhone: Ver.3.1.3
• For clarity in identifying your model of iPod, please see Apple’s own
document “Identifying iPod models” at
http://support.apple.com/kb/HT1353
• This unit does not support video playback from iPod/iPhone, even
using a video-compatible cable.
Setting the iPod Control
When an iPod/iPhone is connected, operate it from its own controls or
from the head unit.
1 Press and hold /ENTER/OPTION for at least 2 seconds
during iPod source.
The Option menu for iPod mode is activated.
2 Turn the Rotary encoder to select APP DIRECT, and then
press ENTER.
The iPod control mode will be switched between iPod MODE
and HU MODE.
HU (HEAD UNIT) MODE:
Operate the iPod/iPhone via this unit.
This mode allows you to use M.I.X. play, repeat and music search in
an iPod/iPhone from the head unit.
Note
• In HU MODE, if you operate from an iPod/iPhone, the head unit’s
display and operations may not correspond with those of the iPod/
iPhone.
iPod MODE:
Operate the iPod/iPhone using its own controls. When iPod MODE
is selected, some functions will not be operable via the head unit.
Notes
• During HU MODE, you can switch to iPod MODE directly by pressing
OBAND.
• Once the control mode is changed, the iPod/iPhone is paused. Press
 to continue.
Playback
1 Press VSOURCE to switch to the iPod source.
2 Press  or  to select the desired song.
Pressing and holding  or  will fast backward/fast
forward the current track.
3 To pause playback, press .
Pressing  again will resume playback.
Notes
• A song playing on the iPod/iPhone while it is connected to this unit will
continue to play from where it was paused after disconnection.
• If you listen to an episode from a selected Podcast or Audiobook, the
episode can be changed by pressing  or .
• An episode may have several chapters. The chapter can be changed by
pressing  or .
Searching for a desired Song
An iPod/iPhone can contain hundreds of songs. Use one of the search
modes listed below, that you deem most effective in finding a desired
song.
Each music category has its own individual hierarchy. Use the Playlist/
Artist/Album/Song/Podcast/Genre/Composer/Audiobook/Genius Mix
List search mode to narrow searches based on the table below.
For example:
Searching by Artist name
The following example explains how an ARTIST search is performed.
Selecting another search category operates in the same manner but
using a different hierarchy.
1 Press ENTER to activate the search selection mode.
2 Turn the Rotary encoder to select the ARTIST search
mode, and then press ENTER.
SHUFFLEALL
*1
 PLAYLIST  ARTIST  ALBUM  SONG 
PODCAST  GENRE  COMPOSER  AUDIOBOOK 
GENIUS MIX
*2/*3
 SHUFFLEALL
*1 Refer to “Random Play Shuffle (M.I.X.)” on page 41.
*2 Depending on the connected iPod/iPhone, Genius Mix function
may not be supported.
*3 When an iPod/iPhone with Genius Mix List created by iTunes is
connected to this unit, GENIUS MIX search mode can be used
to search a Genius Mix List.
Note
• The display of search mode list varies depending on the setting of iPod
LIST. For details, refer to “iPod/iPhone Search Mode Setting” on
page 29.
3 Turn the Rotary encoder to select the desired Artist, and
then press ENTER.
4 Turn the Rotary encoder to select the desired Album, and
then press ENTER.
5 Turn the Rotary encoder to select the desired Song, and
then press ENTER.
Notes
• This function is unavailable when iPod MODE is selected in “Setting
the iPod Control” (refer to “Setting the iPod Control” on page 39). And
“iPod CONTROL” will be displayed.
Hierarchy 1 Hierarchy 2 Hierarchy 3 Hierarchy 4
Playlist Song — —
Artist
*
Album
*
Song —
Album
*
Song — —
Song———
Podcast Episode — —
Genre
*
Artist
*
Album
*
Song
Composer
*
Album
*
Song —
Audiobook — — —
Genius Mix List———

Alpine CDE-W265BT Specifications

General

MP3 playback	Yes
Operating temperature (T-T)	-10 - 60 °C
Bluetooth version	2.1+EDR
Bluetooth profiles	A2DP, AVRCP, HFP, OPP, PBAP, SPP
DIN size	2 DIN
Output power	200 W
Product color	Black
Disc types supported	CD, CD-DA, CD-R, CD-RW
Equalizer bands quantity	9
Signal-to-Noise Ratio (SNR)	105 dB
AM band range	530 - 1710 kHz
FM band range	87.7 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	18
Card reader integrated	No

Weight and Dimensions

Weight	1850 g
Dimensions (WxDxH)	178 x 161.7 x 100 mm
