Alpine CDE-W265BT User Manual

57-EN
1 Remove the detachable front panel.
2 Insert the bracket keys into the unit, along the guides on
either side. The unit can now be removed from the
mounting sleeve.
 CDE-W265BT
 CDE-164BT
3 Pull the unit out, keeping it unlocked as you do so.
JAPANESE CAR
 CDE-W265BT
 CDE-164BT
Mounting the Microphone
For the sake of safety, mount the microphone in the following location.
• In a stable and secure location.
• In a location that does not inhibit safely driving the vehicle.
• Mount the microphone in a location where the driver’s voice can
easily be picked up.
Choose a location for the microphone that can easily pick up the drivers
voice. Requiring the driver to move towards the microphone for
audibility causes a distraction that could be dangerous.
Removal
Bracket keys
(Included)
This unit
Bracket keys
(Included)
This unit
Front Frame
Screw (M5 × 8)
(Included)
Mounting
Bracket
Front Frame
Screw (M5 × 8)
(Included)
This unit
Mounting
Bracket
Cable clamp
(Sold separately)
Microphone

Alpine CDE-W265BT Specifications

General

MP3 playback	Yes
Operating temperature (T-T)	-10 - 60 °C
Bluetooth version	2.1+EDR
Bluetooth profiles	A2DP, AVRCP, HFP, OPP, PBAP, SPP
DIN size	2 DIN
Output power	200 W
Product color	Black
Disc types supported	CD, CD-DA, CD-R, CD-RW
Equalizer bands quantity	9
Signal-to-Noise Ratio (SNR)	105 dB
AM band range	530 - 1710 kHz
FM band range	87.7 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	18
Card reader integrated	No

Weight and Dimensions

Weight	1850 g
Dimensions (WxDxH)	178 x 161.7 x 100 mm
