Alpine CDE-W265BT - Specifications; FM TUNER SECTION; AM TUNER SECTION; CD PLAYER SECTION

54-EN
Specifications
FM TUNER SECTION
AM TUNER SECTION
CD PLAYER SECTION
PICKUP
USB SECTION
BLUETOOTH SECTION
GENERAL
* Primary amplifier ratings per CEA-2006 Standard
• Power output: measured at 4 Ohms and ≤ 1% THD+N
• S/N: 80 dBA (reference: 1 W into 4 Ohms)
CHASSIS SIZE (CDE-W265BT)
CHASSIS SIZE (CDE-164BT)
NOSEPIECE SIZE (CDE-W265BT)
NOSEPIECE SIZE (CDE-164BT)
Note
• Due to continuous product improvement, specifications and design are
subject to change without notice.
Tuning Range 87.7 ~ 107.9 MHz
Mono Usable Sensitivity 9.3 dBf (0.8 µV/75 ohms)
50 dB Quieting Sensitivity 13.5 dBf (1.3 µV/75 ohms)
Alternate Channel Selectivity 80 dB
Signal-to-Noise Ratio 65 dB
Stereo Separation 35 dB
Capture Ratio 2.0 dB
Tuning Range 530 ~ 1,710 kHz
Sensitivity (IEC Standard) 22.5 V/27 dB
Frequency Response 5 ~ 20,000 Hz (±1 dB)
Wow & Flutter (% WRMS) Below measurable limits
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
Wave length 795 nm
Laser power CLASS I
USB requirements USB 1.1/2.0
Max. Power Consumption Smartphone charge-capable
USB Class Mass Storage
File System FAT 12/16/32
MP3 Decoding MPEG AUDIO Layer-3
WMA Decoding Windows Media
™
Audio
Bluetooth Specification Bluetooth v2.1 + EDR
Output Power +4 dBm Max. (Power class 2)
Profile HFP (Hands-Free Profile)
A2DP (Advanced Audio
Distribution Profile)
AVRCP (Audio/Video Remote
Control Profile)
Power Requirement 14.4 V DC
(11 ~ 16 V allowable)
Power Output 18 W RMS × 4
*
Maximum Pre-Output Voltage 4 V/10 k ohms
Bass ±9.1 dB at 100 Hz
Treble ±9.1 dB at 10 kHz
Weight 1.85 kg (4 lbs. 6 oz)
(CDE-W265BT)
1.4 kg (3 lbs. 1 oz)
(CDE-164BT)
Width 178 mm (7")
Height 100 mm (4")
Depth 161.7 mm (6–3/8")
Width 178 mm (7")
Height 50 mm (2")
Depth 164.7 mm (6–1/2")
Width 169.8 mm (6–3/4")
Height 95.8 mm (3–3/4")
Depth 26.2 mm (1")
Width 169.8 mm (6–3/4")
Height 45.8 mm (1–13/16")
Depth 24 mm (15/16")
