31-EN
Specifications
Performance
Power Output Rated: 4Ω, 14.4V, 10%THD CH1-6: 50W, CH7-8: 150W
RCA Output Rated: 10kΩ, 14.4V, 0.1%THD CH1-8: 4Vrms
THD+N High level: 2Vrms into 4Ω ≤0.1%
RCA: 2Vrms into 10kΩ ≤0.06%
S/N High level: 40k-AES17+A-weighted ≥80dB
RCA: 40k-AES17+A-weighted ≥95dB
Input Voltage High level 26Vpp
RCA 11Vpp
Output Voltage High level CH1-6: 40Vpp, CH7-8: 70Vpp
RCA 4Vrms
Frequency Response 20Hz~40kHz
General
Input Impedance High level >50kΩ
RCA >50kΩ
System Sampling Rate 192kHz/32bit
Operating Voltage 9~16V
Operating Temperature -20°C~+60°C
BACK UP CURRENT (12.6V) ≤3mA
REM Start Input High level (H1-/H1+), ACC optional
REM Start Output 12V (0.2A)
Weight 2.4kg
Dimensions Length 225mm
Width 220.5mm
Height 54mm
