Alpine PXE-M60-4 - Description of PC Software

15
1
Temperature display
Detect the temperature on the device surface.
2
File
Load or save scene files on PC, load or save all scene files.
3
Options
Firmware update, noise gate, restore factory settings, shutdown delay, switch between
English and Chinese, check the version number.
4
Encryption
Enter a 6-digit encryption password to encrypt the tuned sound effect data.
5
EQ gain step size
Step size can be chosen from the range: 0.1dB ~ 0.5dB ~ 1.0dB.
6
Mute button
Mute the master volume
7
Master volume
Push the fader left and right to adjust the master volume in the range of 0 ~ 35.
8 Homepage
Master audio source selection (High Level and Bluetooth), Mix audio source selection
(High Level, Bluetooth and OFF), master audio source attenuation adjustment, pre-set sound
effects recall and saving, and recall of multiple sets of online sound effects are supported.
9
EQ
Enter the EQ interface to go to the professional tuning interface.
10
TCR Enter the Time Correction interface, set the delay value, unit of delay and delay group.
11
Mix Enter the Mix interface, Sound mixing and Frequency mixing setting.
12
Output channel display
Display the output channel curve.
13
EQ curve
Display the current EQ curve status, set the frequency, Q value and gain.
14
Frequency, Q value,
Gain
Adjust the frequency, Q value and gain of the output channel. The gain is adjustable but the
frequency and Q value are fixed in the Graphic EQ interface. The frequency, Q value and
gain are all adjustable in the Parametric EQ interface.
15
Parametric EQ, Graphic
EQ
Switch between Parametric EQ mode and Graphic EQ mode. Mode switch would lead to
loss of all settings.
16 Low-pass filter
Turn on or off the low-pass filter to cut off high frequency.
Select filter type (Linkwitz-Riley, Butterworth or Bessel).
Select the divider frequency (between 20Hz and 20kHz).
Select the divider slope (-6dB/Oct, -12dB/Oct, -18dB/Oct, -24dB/Oct, -30dB/Oct, -
36dB/Oct, -42dB/Oct, or -48dB/Oct).
17 High-pass filter
Turn on or off the high-pass filter to cut off low frequency.
Select filter type (Linkwitz-Riley, Butterworth or Bessel).
Select the divider frequency (between 20Hz and 20kHz).
Select the divider slope (-6dB/Oct, -12dB/Oct, -18dB/Oct, -24dB/Oct, -30dB/Oct, -
36dB/Oct, -42dB/Oct, or -48dB/Oct).
18
Channel phase
Select the channel phase (normal phase or reverse phase).
19
Channel gain
Push the fader left and right to adjust the channel gain, that it, to adjust the volume of the
output channel; the adjustable range is: -60dB ~ +6dB.
20 Reset channel type
Select "Clear" to set the current channel type as Empty; select "Default" to set the current
channel type as Factory setting.
21
Locking
You can lock the current channel type.
22
Sync
The syncing modes to choose from include “Copy channel EQ / volume from left to right”
or “Copy channel EQ / volume from right to left”.
23
Direct EQ, Restore EQ
Switch the tuned EQ data to direct state, click it again to restore the EQ data before Direct
EQ setting.
24
Reset EQ
Reset EQ setting.
25
Output channel
There are 6 output channels to choose from. Configure the type of output channel. Click the
speaker button to mute.
26
Connection indicator
Connect the PC and the host machine with a USB cable. Open the software to connect the
device. Click it again to turn off the connection.
