Alpine PXE-M60-4 - Specifications

16
Dynamic range
≥98dB
SNR (RCA)
≥95dB
Background noise
High level: 75uVrms; RCA: 12uVrms
Channel resolution
≥75dB
THD
≤0.01%
Input voltage
High level: 28Vpp
Output voltage
High level: 28Vpp; RCA: 6.5Vpp
Rated power
4CHX25W (4Ω, 14.4V, 1kHz, 10%THD)
Maximum power
4CHX50W (4Ω, 14.4V, 1kHz, 10%THD)
Input / output sensitivity
1:1.25 (no power amplification)
Frequency response
20Hz 〜 20kHz
System sampling rate
48kHz/24bit
Input impedance
High level: 20Ω
Output impedance
51Ω
Operating voltage
9〜16V
Quiescent current
≤2.3mA (in off state)
Stand-by power consumption
≤0.1W
REM startup input
High level (FL-/FL+) or AAC optional
REM startup output
12V (0.2A)
Startup time
10s
Operating ambient temperature
-20~60°C
Storage temperature
-40~85°C
Net weight
1.2kg
Dimensions
160mmX140mmX38mm
Specifications
