Alpine UTX-M06 - Specifications; Functional Parameters

25
Specification parameters
Interface
USB 2.0/MICRO SD
Capacity
Supports a maximum of 128G each
Maximum power consumption
1.5A
File system
FAT16/32
Maximum number of playable
tracks
5000 tracks
PCM encoding
192kHz，16~24bit
MP3 decoding
MPEG Audio Layer-3
WMA decoding
Windows Media™ audio
WAV decoding
waveform audio file
FLAC decoding
Free Lossless Audio Codec
APE decoding
Monkey's Audio
Audio format supported by
Bluetooth
AAC/SBC
System sampling rate
96kHz/24bit
Power supply requirements
14.4V DC (allowable 9~16V)
Controller screen
2.4 inches color TFT display (480×320)
Net weight
0.77kg
Dimensions of host machine
178mm×143.6mm×50mm
Dimensions of controller
111mm×50mm×17.5mm
Functional parameters
Input signals
4 channels of high level, 2 channels of RCA audio and high resolution blue tooth
Output signals
4 channels of high level, 6 channels of RCA audio
Signal gain of output channel
Range: mute, -60dB~+6dB
Output signal equalizer
Type: parametric EQ, graphic EQ
Frequency: 20Hz~20kHz, resolution: 1Hz
Q value (slope or gradient): 0.404~28.852
Gain: -12.0dB~+12.0dB, resolution can be selected from 0.1dB~0.5dB~1.0dB
Output signal frequency
divider
Each output channel is equipped with an independent multi-order high-pass filter
Filter type: Butterworth by default, resolution: 1Hz
Filter cross-over frequency: 20Hz~20kHz
Filter slope (gradient): -6dB/Oct ~ -48dB/Oct
Output phase
Normal phase or reverse phase
Output delay
0.00~10.42ms、0.0~354.3cm、0.0~139.6inch
Pre-set sound effects
6 sets of pre-set sound effect data can be saved in the device
