Using the System
22
Signal Name FPGA Pin No.
Description
HEX0[0] PIN_AF10 Seven Segment Digital 0[0]
HEX0[1] PIN_AB12 Seven Segment Digital 0[1]
HEX0[2] PIN_AC12 Seven Segment Digital 0[2]
HEX0[3] PIN_AD11 Seven Segment Digital 0[3]
HEX0[4] PIN_AE11 Seven Segment Digital 0[4]
HEX0[5] PIN_V14 Seven Segment Digital 0[5]
HEX0[6] PIN_V13 Seven Segment Digital 0[6]
HEX1[0] PIN_V20 Seven Segment Digital 1[0]
HEX1[1] PIN_V21 Seven Segment Digital 1[1]
HEX1[2] PIN_W21 Seven Segment Digital 1[2]
HEX1[3] PIN_Y22 Seven Segment Digital 1[3]
HEX1[4] PIN_AA24 Seven Segment Digital 1[4]
HEX1[5] PIN_AA23 Seven Segment Digital 1[5]
HEX1[6] PIN_AB24 Seven Segment Digital 1[6]
HEX2[0] PIN_AB23 Seven Segment Digital 2[0]
HEX2[1] PIN_V22 Seven Segment Digital 2[1]
HEX2[2] PIN_AC25 Seven Segment Digital 2[2]
HEX2[3] PIN_AC26 Seven Segment Digital 2[3]
HEX2[4] PIN_AB26 Seven Segment Digital 2[4]
HEX2[5] PIN_AB25 Seven Segment Digital 2[5]
HEX2[6] PIN_Y24 Seven Segment Digital 2[6]
HEX3[0] PIN_Y23 Seven Segment Digital 3[0]
HEX3[1] PIN_AA25 Seven Segment Digital 3[1]
HEX3[2] PIN_AA26 Seven Segment Digital 3[2]
HEX3[3] PIN_Y26 Seven Segment Digital 3[3]
HEX3[4] PIN_Y25 Seven Segment Digital 3[4]
HEX3[5] PIN_U22 Seven Segment Digital 3[5]
HEX3[6] PIN_W24 Seven Segment Digital 3[6]
HEX4[0] PIN_U9 Seven Segment Digital 4[0]
HEX4[1] PIN_U1 Seven Segment Digital 4[1]
HEX4[2] PIN_U2 Seven Segment Digital 4[2]
HEX4[3] PIN_T4 Seven Segment Digital 4[3]
HEX4[4] PIN_R7 Seven Segment Digital 4[4]
HEX4[5] PIN_R6 Seven Segment Digital 4[5]
HEX4[6] PIN_T3 Seven Segment Digital 4[6]
HEX5[0] PIN_T2 Seven Segment Digital 5[0]
HEX5[1] PIN_P6 Seven Segment Digital 5[1]
