HEX5[2] PIN_P7 Seven Segment Digital 5[2]
HEX5[3] PIN_T9 Seven Segment Digital 5[3]
HEX5[4] PIN_R5 Seven Segment Digital 5[4]
HEX5[5] PIN_R4 Seven Segment Digital 5[5]
HEX5[6] PIN_R3 Seven Segment Digital 5[6]
HEX6[0] PIN_R2 Seven Segment Digital 6[0]
HEX6[1] PIN_P4 Seven Segment Digital 6[1]
HEX6[2] PIN_P3 Seven Segment Digital 6[2]
HEX6[3] PIN_M2 Seven Segment Digital 6[3]
HEX6[4] PIN_M3 Seven Segment Digital 6[4]
HEX6[5] PIN_M5 Seven Segment Digital 6[5]
HEX6[6] PIN_M4 Seven Segment Digital 6[6]
HEX7[0] PIN_L3 Seven Segment Digital 7[0]
HEX7[1] PIN_L2 Seven Segment Digital 7[1]
HEX7[2] PIN_L9 Seven Segment Digital 7[2]
HEX7[3] PIN_L6 Seven Segment Digital 7[3]
HEX7[4] PIN_L7 Seven Segment Digital 7[4]
HEX7[5] PIN_P9 Seven Segment Digital 7[5]
HEX7[6] PIN_N9 Seven Segment Digital 7[6]
Table 3.6 Pin Assignment for 7-SEG Display
Signal Name FPGA Pin No.
Description
LCD_DATA[0] PIN_J1 LCD Data[0]
LCD_DATA[1] PIN_J2 LCD Data[1]
LCD_DATA[2] PIN_H1 LCD Data[2]
LCD_DATA[3] PIN_H2 LCD Data[3]
LCD_DATA[4] PIN_J4 LCD Data[4]
LCD_DATA[5] PIN_J3 LCD Data[5]
LCD_DATA[6] PIN_H4 LCD Data[6]
LCD_DATA[7] PIN_H3 LCD Data[7]
LCD_RW PIN_K4 LCD Read/Write Select, 0 = Write, 1 = Read
LCD_EN PIN_K3 LCD Enable
LCD_RS PIN_K1 LCD Command/Data Select, 0 = Command, 1 = Data
LCD_ON PIN_L4 LCD Power ON/OFF
LCD_BLON PIN_K2 LCD Back Light ON/OFF
Table 3.7 Pin Assignment for 16x2 LCD Module
