Using the System
38
FL_ADDR[15] PIN_AD16 FLASH Address[15]
FL_ADDR[16] PIN_AE16 FLASH Address[16]
FL_ADDR[17] PIN_AC15 FLASH Address[17]
FL_ADDR[18] PIN_AB15 FLASH Address[18]
FL_ADDR[19] PIN_AA15 FLASH Address[19]
FL_DQ[0] PIN_AD19 FLASH Data[0]
FL_DQ[1] PIN_AC19 FLASH Data[1]
FL_DQ[2] PIN_AF20 FLASH Data[2]
FL_DQ[3] PIN_AE20 FLASH Data[3]
FL_DQ[4] PIN_AB20 FLASH Data[4]
FL_DQ[5] PIN_AC20 FLASH Data[5]
FL_DQ[6] PIN_AF21 FLASH Data[6]
FL_DQ[7] PIN_AE21 FLASH Data[7]
FL_CE_N PIN_V17 FLASH Chip Enable
FL_OE_N PIN_W17 FLASH Output Enable
FL_RST_N PIN_AA18 FLASH Reset
FL_WE_N PIN_AA17 FLASH Write Enable
Table 3.17 Pin Assignment for FLASH
