O&C MANUAL #8311 • TH/III FAMILY
PG. 11
SECTION 4 PRINTER OPTION SECTION 4
Connecting the Printer to the Oven
1. On the printer, using your printer operation manu-
al, locate the dip switch panel on the lower left
side. Remove the panel cover and set all switches
to the up (on) position. The printer should be
shipped with all switches in the up position. Set
the second switch from the right to the down (off)
position. Set the fifth switch from the left to the
down (off) position. If printing in a language other
than English, consult Table A for appropriate
switch settings.
2. Locate the serial data port on the rear panel of the
oven, just to the left of the cooling fan inlet. Attach
the serial data cable to this port. Using the printers
operation manual, locate its serial data port and
connect the serial data cable.
3. The printer's power switch is located on the bottom
right side. Turn on the printer. Ensure that the
printer's green power and on-line indicators are
illuminated. Refer to Chapter Three of the printer
operation manual if these are not illuminated.
4. Turn on the cook and hold oven and you will see a
print out of some of the oven's basic configuration.
The electronic cook and hold oven is equipped with a serial data port for connection to
an optional serial printer in order to obtain a printed report of temperature recording data
(HACCP protocol) as well as setup and diagnostic information. The control has enough
memory to store 120-150 temperature samples as a total for all reports combined. Temperature
samples are read through the product probe. Only the tip of the product probe senses the inter-
nal product temperature, therefore, it is important the tip be placed correctly in the product for
accuracy. These reports can be printed in English, French, German or Spanish.
A 9-pin serial data port is located at the back of the oven near the cooling fan. This port can
be used to connect the serial data printer to the oven in order to take advantage of the data
reporting capabilities.
In order to ensure the proper cable and the correct printer switch settings, we recommend
purchasing your printer from Alto-Shaam:
Serial Printer & Cable Package — 125/208-240V . . . . . . . . Part # 14218
230 V . . . . . . . . . . . . . . Part # 14679
Serial Printer Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . Part # PO-33397
The printers are shipped with a users manual. It is recommended that you read the first
four chapters in order to understand how to operate and service the printer. This is necessary
in order to load the paper, change the printer ribbon, and understand it's operation. To begin
printer set up, you must first load the paper, print ribbon and connect the power supply. Place
the printer in a convenient spot near the oven.
Do NOT place the printer on top of the oven on the left side. The paper
may block the air inlet fan and cause overheating of the electronic controls.
IMPORTANT
Switch Position Comment
1-1 Up
1-2 Down
1-3 Up
1-4 Up
1-5 Down Flow Control:
X-ON / X-OFF
1-6 Up
1-7 Up
1-8 Up
2-1 Up Up: English
Down: French
German
Spanish
2-2 Up Up: English
French
Spanish
Down: German
2-3 Up
2-4 Up
Table A
