CLARKE TECHNOLOGY Operator's Manual - Encore S2426/L2426 Page -39-
CLARKE TECHNOLOGY Encore S2426/L2426
Control Panel Assembly Parts List 8/00
Qty Qty
Ref. # Part No. Description “L” “S”
1 55413A Key (included w/Item 3) Ref Ref
2 84237A Screw, 10-32 x ½ 2 2
3 47380A Switch, Key 1 1
4 60334A Panel, Key Switch 1 1
5 80108A Screw, 10-24 x ½ SS Black Xylan 8 8
6 87052A Washer, Switch 1 1
7 962262 Screw, Set 8-32 x ½ (included in item 29) 4 2
8 50962A Traverse, Control Knob 1 -
9 85703A Screw, 10-00 x ½ PN 1 1
10 962957 Screw, 10-16 2 -
11 40135A Harness, Potentiometer Assembly. 1 -
12 60259A Bracket, Traverse Switch 1 -
13 980666 Washer, 3/8 Starlock 1 -
14 40158A Switch, Reverse 1 -
15 980603 Washer 4 2
16 920224 Nut, 10-32 Hex 4 2
17 30062A Control Handle 1 -
30072A Control Handle - 1
18 85391A Screw, ¼-20 x
1
/2 SS Ref Ref
19 87026A Washer, ¼ SS Ref Ref
20 44308B Control, Solution 1 1
21 41422A Breaker, Circuit 25 Amp Traverse 1 -
22 41433A Breaker, Circuit 40 Amp Brush 2 2
23 41448A Breaker, Circuit 30 Amp Vac 1 1
24 41423A Breaker, Circuit 5 Amp Actuator 1 1
25 70186A Label, Control “L” 1 -
70187A Label, control “S” - 1
26 60258A Panel, Control, Metal 1 1
27 40217B Meter, Battery 1 1
28 40168A Switch, Brush Adjustment 1 1
29 55502A Knob 1 1
30 51057A Meter, Brush 1 1
31 962330 Screw, 6-32 x
3
/8 44
32 980608 Washer 4 4
33 30056A Housing, Switch & Lever 2 2
34 30055A Lever, Switch 2 2
35 50961A Spring, Switch 4 4
36 40126A Switch, Forward/Reverse 2 2
37 80104A Screw, 10-32 x ½ SS Black Xylan 4 4
38 70219A Label, Key Switch 1 1
39 34264A Gasket, Panel 1 1
40 30096A Gasket, Switch 1 1
NI 47708A ¼ F.I.M.Q.D. 4 2
NI 47712A ¼ F.I.F.Q.D. 1 0
NI 912226 Meter, Hour (Optional)
