CLARKE TECHNOLOGY Operator's Manual - Encore S2426/L2426 Page -41-
Ref. # Part No. Description Qty
1 61263A Bracket Tube 1
2 85730A Screw, 3/8-16 x 1¼, Hex SS 1
3 980638 Lockwasher, 3/8 LT Spring Type 1
4 69860B Bracket, Pin 1
5 87026A Washer, ¼ SS 2
6 170915 Screw, ¼-20 x ¾ 4
7 962481 Screw, ¼-20 x 1¼ Hex 2
8 87031A Washer, 3/8 Flat 3
9 920208 Nut, ¼-20 2
10 81111A Nut, 3/8-16 ESNA 1
11 80101A Screw, ¼-20 x 3¼ SS 1
12 85811A Screw, 5/16-18 x ¾ 1
13 67867A Nut, spacer 1
14 60256A Squeegee, Pivot Arm 1
15 81104A Nut, ¼ Nylock 5
16 60255A Bracket, Squeegee 1
17 60328A Mount, Squeegee 1
18 81112A Nut, 5/16-18 Thin ESNA SS 1
19 Page 37 Cable, Squeegee Lift Ref
20 Page 37 Lift Handle Assembly Ref
21 920346 Palnut Ref
22 980651 Washer 1
CLARKE TECHNOLOGY Encore S2426/L2426
Squeegee Lift Assembly Parts List 6/00
