CLARKE TECHNOLOGY
Encore S2426/L2426
Brush Head Assembly Parts List 8/00
Drawing #10071A and #10061A
Qty Qty
Ref. # Part No. Description L S
1 38708A Washer, Spacer Nylon 2 2
2 50950A Actuator 1 1
3 60265A Plate, Nut 2 2
4 47374A Switch, Lever 1 1
5 47422B Switch, Whisker 1 1
6 980608 Washer, #6 4 4
7 962980 Screw, 6-32 x 1 4 4
8 60251A Mount, Switch 1 1
9 82501A Pin 1 1
10 60236A Bracket, Brush Head 1 1
11 766780 Pin, Hair 5 5
12 85838A Screw, ½ x 20 x 1½ 4 4
13 980673 Washer 4* 4*
14 63058A Bar, Linkage 4 4
15 67705B Bearing, Sleeve 8 8
16 920278 Nut, ½-20 SS 8 8
17 980626 Washer, ½ Lock 4 4
18 80100A Screw, ½-20 x 1 Hex Head 4 4
19 80091A Pin, Brush Lift 1 1
20 60239A Mount, Brush Head 1 1
21 81217A Nut, ¼-20 ESNA .218 Height 3 3
22 60335A Bracket, Brush Housing 1 1
23 170915 Screw, ¼-20 x ¾ SS 2 2
24 782002 Clamp, Hose 2 2
25 81104A Nut, ¼-20 ESNA 7 7
26 34705A Hose, Solution 2 2
27 722030 Clamp, Hose 2 2
28 962989 Screw, ¼-20 x 1½ 2 2
29 38014A Solution Splitter Ref Ref
30 60235A Plate, Brush Head 1 1
31 962992 Screw, 8-32 x 5/8 SS 4 4
32 55721A Latch, Brush Housing 1 1
33 30053A Housing, Left Brush 1 1
34 30051A Skirt, Left 1 1
35 85616A Screw, 10-32 x 5/8 SS 12 12
36 82004A Nut, “T” 10-32 12 12
37 81109A Nut, 8-32 SS ESNA 4 4
38 60337A Plate, Latch Brush 2 2
39 Page 24 Brush/Pad Assemblies
* Used only as required to square up linkage bar #14 to the
frame.
Qty Qty
Ref.# Part No. Description L S
40 962714 Screw, 5/16-18 x ¾ Soc. 2 -
85811A Screw, 5/16-18 x ¾ Hex - 2
41 34400B Gimbal Male 2 -
20308A Motor, Adapter - 2
42 61658A Gimbal, Collar 2 -
43 59856A Washer, Rubber 2 -
44 980652 Washer, 5/16 Lock - 2
45 980210 Washer, Impeller - 2
46 980679 Washer, Spacer - 2
47 962244 Screw, 3/8-16 x ¾ 8 8
48 980638 Washer, Lock 3/8 8 8
49 30052A Skirt, Right 1 1
50 30054A Housing, Right Brush 1 1
51 55451A Keeper 1 1
52 87039A Washer, ¼ 2 2
53 30048A Wheel, Guide 1 1
54 60248A Sleeve Guide Wheel 1 1
55 85301A Screw, ¼-20 x 1¼ 1 1
56 20014A Spacer, Brush Tilt - 2
57 915102 Key (included w/Item 58) 2 2
58 44809B Motor, Brush 2 2
59 41602A Housing 4 4
60 41601A Connector 4 4
61 60240A Bushing, Swivel Adj., ¼ 4 4
62 50839A Pin, Plunger 1 1
63 50956A Spring, Plunger 1 1
64 50957A Knob 1 1
65 60241A Bushing, Swivel, 3/8 1 1
66 81105A Nut, 3/8-16 SS ESNA 1 1
67 53422A Spring, Head Pressure 1 1
68 87007A Washer, Flat, ¼” 1 1
69 60238A Tube, Head Pressure 1 1
70 60249A Switch, Actuator 1 1
71 80102A Washer, ¼ 1 1
72 85702A Screw, ¼-20 x 1¾ 1 1
73 87031A Washer, 3/8 Flat Ref Ref
74 80109A Nut, ½-20 Jam S.S. 4 4
75 980603 Washer, #10 2 2
76 80108A Screw, 10-24 x ½ 2 2
77 30092A Insulator, Mylar 1 1
NI 77091A Label, Moving Parts 2 2
CLARKE TECHNOLOGY Operator's Manual - Encore S2426/L2426 Page -47-
